Channels 4 - 2

POWER SUPPLY

Power supply voltage / fuse: 11 ÷ 15 VDC / 1 x 15 A

Idling current (power ON/OFF) 1.2 A / 0.04 mA

Consumption @ 2 Ω, 14.4 VDC (Max Musical Power): 15 A

Remote In: 4 ÷ 15 VDC - 1 mA

ART: Automatic Remote Turn-On/Off

AMPLIFIER STAGE

Distorsion - THD (100 Hz @ 4Ω) 0.2 %

Bandwidth: 10 ÷ 30K Hz

S/N Ratio (A weighted @ 1 V): 95 dB

Damping factor (100 Hz @ 4Ω) 45

Pre-In sensitivity: LO: 0.2 ÷ 5 V

HI: 0.8 ÷ 20 V

Load impedance (MIN)

@ 4 Ch:

@ 2 Ch:

2Ω

4Ω

Max size (mm/in): 223 x 100,5 x 43,6 / 8.77 x 3.95 x 1.71

Weight (kg/lb): 1.35 / 2.97

Adjustable Crossovers yes

    Output Power

OUTPUT POWER (RMS) @ 14.4 VDC, THD 1%:

4 Ch 50 W x 4 (4 Ω)

4 Ch 65 W x 4 (2 Ω)

3 Ch 50 W x 2 (4 Ω) + 130 W x 1 (4 Ω)

3 Ch 65 W x 2 (2 Ω) + 130 W x 1 (4 Ω)

2 Ch 130 W x 2 (4 Ω)

OUTPUT POWER (RMS) @ 14.4 VDC, THD 10%:

4 Ch 60 W x 4 (4 Ω)

4 Ch 75 W x 4 (2 Ω)

3 Ch 60 W x 2 (4 Ω) + 150 W x 1 (4 Ω)

3 Ch 75 W x 2 (2 Ω) + 150 W x 1 (4 Ω)

2 Ch 150 W x 2 (4 Ω)

Total Power RMS 600 W

    INPUTS / FILTERS

Inputs: PRE IN

FRONT Ch. filters FULL: Yes

Lo-Pass: 65-85-115 Hz @ 12 dB/Oct

REAR Ch. filters FULL Yes

Hi-Pass: 65-85-115 Hz @ 12 dB/Oct

Lo-Pass: 65-85-115 Hz @ 12 dB/Oct.
