Technical Specs

Component SPL COAXIAL

Size mm (in.) 165 (6.5)

Power Handling - ContinuousW 100

Power Handling - Peak W 200

Impedance Ohm 4

Tweeter diaphragm mm (in.) PEI

Woofer Voice Coil Ø mm (in.) 38 (1.5)

Tweeter Voice Coil Ø mm (in.) 28 (1.1)

Frequency Response Hz 100 ÷ 20k

Woofer Magnet size D x d x hmm (in.) 70 x 45 x 7 (2.76 x 1.77 x 0.28)

Tweeter Magnet size D x h mm (in.) 19 x 3 (0.75 x 0.12)

Weight of one speaker kg (lb.) 0,94 (2.08)

Woofer Magnet Special Neodymium N38 H

Tweeter Magnet Special Neodymium N38 H

Cone Water repellent pressed paper

Technical Specs

Electro-acoustic Specs

D mm 128

Re Ohm 3,3

Fs Hz 110

Le mH 0,061

Vas I 4,92

Mms g 10,14

Cms mm/N 0,21

BL T*m 5,83

Qts 0,64

Qes 0,68

Qms 9,7

Spl dB 96,5
